　Introduction of Shimano Equipments

6 spindles automated lathe machine

For mass production, Shimano is operating 6 spindles automated lathe machines for long years.
And those are operated by highly trained experts.

Name of machine	Maker	Specification	No. of units
6 spindles automated lathes	Schütte	6 Spindles	7
	Tsugami	Ditto	20
	Mitsubishi	Ditto	4
	Gildemeister	Ditto	3
	Okuma	Ditto	24
Total			58

NC Lathe machines

Shimano has built 3^rd facility in main factory in 2015 with implement of advanced NC machines.

Name of machine	Maker	Specification	No. of units
NC Lathes	Mori.	Sub Spindle type	3
	Tsugami	Ditto	16
	Citizen	Ditto	21
	Okuma	Ditto	1
	Nakamura-Tome	Ditto	2
	Okuma	Single Spindle type	1
	Takizawa	Ditto	2
	Akebono	Ditto	10
Total			56

Name of machine	Maker	Specification	No. of units
NC Lathes	Mori	2 Spindles Chucker	47
	Takahashi	Ditto	16
	Takamatsu	Ditto	1
	Murata	Ditto	12
	Citizen	Ditto	1
	Mori	Single Spindle Chucker	51
	Takamatsu	Ditto	11
	Okuma	Ditto	1
	Nakamura-Tome	Ditto	5
	Takizawa	Ditto	4
	Tamaki	Ditto	8
	Ozaki	Ditto	2
Total			159

Secondary processing equipment

Shimano is available for tapping, racking and polygonal machining for products.
And also available for barrel polishing and burring, automated assembling.　　　　

Name of Machines	No. of units
NC end face polishing	5
NC surface polishing	1
NC honing	1
NC Centerless	1
Centerless	7
Rolling	31
Tapping	20
Racking	10
Milling	11

Name of Machines	No. of units
Hydraulic single-purpose machine	19
Automatic assembling	1
Polygonal Machining	18
Electric discharging	1
Burring	1
Automated Sawing	1
Table Lathe	11
Lathe	1
Washing	23
Total	163

Precision Measurement

For keeping high quality, Shimano has advanced measuring machines in clean environment.

Name of Machines	Maker	No. of units
Circularity	Tokyo Seimitsu	1
Contour	Ditto	2
roughness	Ditto	2
Image Dimension	Keyence	1
Microscope	Topcon	1
Hardness tester	Akashi	2
Projector	Mitutoyo	4
Microscope	Nikon	25
Microscope	Topcon	5
Magnifier	Ohtsuka	23
Digital Indicator	Mitutoyo	37
Total		103
